Edible Oil Bottle Making Machine
This is 5L 2 cavities plastic bottle blow molding machineļ¼machine is fully automatic with preform holder, suitable for 3L-5L PET bottle,the output about 1200-1300BPH . Edible oil bottle making machine features:Stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system. Production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple
Description
Product Description
Edible oil bottle making machine has the characteristics of stable and reliable structure, fast speed, stability, simple maintenance, flexible and convenient mold matching, etc. It adopts a servo control system to meet the need to ensure precision in continuous production. Secondly, this machine is equipped with a microcomputer touch screen to control and adjust the temperature, so that workers can easily adjust the temperature of different bottle types during blow molding. In addition, its servo drive system has the advantages of high positioning accuracy, fast speed, good stability and reliability, and it does not require air source, which is very energy-saving. Based on the fault alarm function, this machine is very easy to maintain and does not cause long downtime.
Product Feature
Edible oil bottle making machine uses a high-quality conveyor belt to automatically feed the preforms, and can also realize fully automatic processing without human intervention. This means you only need to hire a few workers to oversee the entire production process. This machine is fully manufactured in accordance with CE safety standards, and we can provide certificates if customers need. It is also equipped with a variety of safety designs designed to reduce the risk of workers being injured during production. As an adaptable piece of equipment, it is suitable for a variety of industries, including food, beverage, oil and gas, and can help produce bottles of different sizes. In addition, we also provide a series of customization options to help customers create machines that are more in line with actual needs.
Detail Technical Parameter
TYPE | ITEM | UNIT | PARAMETER |
Container | Product material | / | PET |
Container volume | L | 5 (2-cavity) | |
Theoretical output | PCS/H | 1200-1300 | |
Max.neck diameter | mm | 80 | |
Max.bottle diameter | 220 | ||
Max.container height | mm | 500 | |
Mouding | Max.mould plate Dimension(L*W) | mm | 700*520 |
Max.mould thickness | mm | 300 | |
Clamping force | KN | 480 | |
Mould opening stroke | mm | 125 | |
Machine size and weight | Main machine(L*W*H) | mm | 2800*1600*2000 |
Main machine weight | Kg | 2500 | |
Preform Loader Size (L*W*H) | mm | 1500*1200*3000 | |
Preform Loader Size | Kg | 300 | |
Max.heating power | kw | 15-35 |
- Cooperated Brand -
We provide whole line auxiliary equipment and the brand we employee are all famous around the world!

Component List | ||
NO. | NAME | BRAND |
1 | AIR CYLINDER | SMC |
2 | SOLENOID VALVE | CKD |
3 | PLC & TOUCH SCREEN | XINJE |
4 | FREQUENCY CONVERTER | SCHNEIDER |
5 | RELAY | SCHNEIDER |
6 | MEGNETIC INDUCTION SWITCH | FESTO |
7 | ELECTRIC | SCHNEIDER |
8 | LINEAR GUIDE | CHINA TAIWAN HIWIN |
Our Service
Pre Sales Service
* Welcome to visiting our Factory.
* 24 hours on line answer your question.
* According customers' demands,recommending the most suitable machine.
* Take video to show real scenes as client's request.
Delivery&Package
Delivery time: 15days as usual after confirm the bottle design.
Package way:The normal package is wooden box. If export to Europe countries,the wooden box will be fumigated.If container is too tight,we will use PE film for packing or pack it according to customers special request.
Why choose us?
- Our Fully Automatic Machines are designed to be energy-efficient, reducing your operating costs.
- Our pros are lessen prices, dynamic sales team, specialised QC, sturdy factories, top quality services and products for Edible Oil Bottle Making Machine.
- We offer a range of Fully Automatic Machines to suit your specific requirements.
- Our tenet is 'Reasonable prices, efficient production time and best service' We hope to cooperate with more customers for mutual development and benefits.
- Our Fully Automatic Machines are designed to reduce labor and increase efficiency.
- We develop innovation in the fierce market competition, in order to provide better quality assurance and better service to users.
- Our Fully Automatic Machines are designed to increase efficiency and profitability for your business.
- Looking to the future, our company will be based on a new development stage, implement a new development concept and build a new development pattern.
- Our Fully Automatic Machines are designed to minimize waste and maximize productivity.
- Our brand is the crystallization of the continuous development of the enterprise, which is the centralized embodiment of product production and research, professional services, comprehensive competitiveness of the enterprise and corporate culture.
